Solvent Printing Machine Starfire GZC 3202

Name: Solvent Printing Machine Starfire GZC 3202
Brand: MEHTA CAD CAM SYSTEMS PVT. LTD.
Price: 1150000.00 INR
Availability: InStock

Price 1150000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 , , Unit

Solvent Printing Machine Starfire GZC 3202 Specification

Noise Level
80 dB

Interface
USB 2.0 / Ethernet

Power Supply
Single Phase AC Power

Processor Speed
High Speed Processor

Weight
680 kg

Features
High Precision, Robust Structure, Reliable Performance, Continuous Ink Supply System

Humidity %
35%~65%

Cabinet Material
Steel

Processor Type
Industrial Control Board

Working Temperature
15~30

Print Speed
80-150 sqm/h

Function
Solvent Printing

Capacity
Large Format Multi-sheet Handling

Usage & Applications
Billboard, Flex Banner, Vinyl, Canvas, Backlit Film

Print Technology
Starfire Piezo Inkjet

Condition
New

Material
Heavy-duty Metal Frame

Dimensions
L 4800 mm x W 990 mm x H 1400 mm

Gross Power
2800 W

Voltage
AC 220V10%, 50/60Hz

Automatic Grade
Automatic

Color Print Speed
110 sqm/h (4 heads)

Black Print Speed
110 sqm/h (4 heads)

Maximum Paper Size
3200 mm

Maximum Resolution
1200 dpi

Use
Outdoor and Indoor Advertising Printing

Solvent Printing Machine Starfire GZC 3202 Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About Solvent Printing Machine Starfire GZC 3202

Solvent Printing Machine Starfire GZC 3202 is an electrically powered digital printing unit that is equipped with a dual printhead that makes it capable to make high-quality prints for the making of banners, logos, and various other products. The offered fully automated is fixed with a positive pressure ink supply system for continuous delivery of printing ink. The external USB data interface of Solvent Printing Machine Starfire GZC 3202 makes it easier to import digital drawings within the machine to make high-quality prints.

Product details

Media Type	Flex
Brand/Make	GONGZHENG
Weight	1000KG
Ink Type	solvent- ecosolvent
Type	Digital printer
Automation Grade	Automatic
Heads	02
Print Head	Starfire
Power Source	Electric

Technical Specification

ITEM	SPECIFICATIONS
Model	GZC 3202S
Print Head	2 Stafire 1024 (10pl)	2 Stafire 1024 (25pl)
Ink	CMYK solvent eco solvent
Ink Supply System	Positive pressure system with ink basket
Media Type	Banner, Frontlit, Backlit, Vinyl, Film....
Media Delivery System	Automatic media feeding and taking up system with penumatic shaft
Drying System	Pre, mid, post, and extended heater + thermal drying system
Printing Speed	300400dpi 129m²/h, 600400dpi 115m²/h 300600dpi 86m²/h, 600600dpi 76m²/h 300800dpi 67m²/h, 600800dpi 59m²/h	300400dpi 126m²/h, 600400dpi 97m²/h 300600dpi 87m²/h, 600600dpi 65m²/h 300800dpi 68m²/h, 600800dpi 51m²/h
Data Interface	External: USB 2.0 ; Internal; High-speed SCSI
Working Environment	Temp. 23° C ~29° C, Humidity: 50%~80%
Software	PhotoPRINT / Maintop.... +GZ Control Console
Power	50Hz/AC 200v + 10% 15A(Printer)+16A(thermal drying system)
Installed / Package size	LWH (mm) : 4800 * 1000 * 1500 / 4930 * 1150 * 1690
G.W / N.W	1290kgs / 1060kgs

High Precision and Speed for Large Format Printing

Designed for demanding printing tasks, the Starfire GZC 3202 delivers consistent high-speed performance, printing at 80-150 sqm/h. Its configurable Starfire 1024 print heads provide exceptional clarity, while automatic feeding and take-up systems streamline media handling, making it ideal for large advertising projects.

Automated Maintenance and Reliable Ink Supply

Automatic cleaning and moisturizing, paired with a continuous ink supply system, minimize downtime and enhance productivity. This ensures reliable print operations and extends print head life, supporting uninterrupted high-volume production.

Efficient Drying and Safe Operation

An integrated IR heating and fan drying system accelerates ink curing for smudge-free, ready-to-use prints. The robust metal frame, CE certification, and controlled noise level (80 dB) ensure safety and comfort for operators, suitable for both indoor and outdoor setups.

FAQ's of Solvent Printing Machine Starfire GZC 3202:

Q: How does the automatic take-up and feeding system work in the Starfire GZC 3202?

A: The automatic take-up and feeding system simplifies media handling by automatically rolling incoming and printed material, supporting rolls with diameters up to 300 mm. This function helps maintain efficient workflows, particularly for large-format or continuous print jobs.

Q: What media types and thicknesses can the Starfire GZC 3202 accommodate?

A: This printing machine can handle a variety of media types, including flex banners, vinyl, mesh, and canvas, supporting thicknesses up to 1 mm. Its versatility allows for a wide range of advertising and display applications.

Q: When should I perform maintenance on the Starfire GZC 3202 solvent printer?

A: The machine is equipped with automatic cleaning and moisturizing features that help maintain the print heads and ink system. Regular monitoring ensures peak performance; however, following the manufacturer's recommended schedule and checking for software updates is advisable.

Q: Where is the Solvent Printing Machine Starfire GZC 3202 most effectively used?

A: The GZC 3202 is suitable for both indoor and outdoor advertising printing, including billboards, banners, and backlit films. Its robust design and reliable performance make it ideal for professional print shops and production facilities.

Q: What are the benefits of using solvent ink with this printer?

A: Solvent ink offers excellent durability and weather resistance, ensuring vibrant prints that can withstand outdoor exposure. This makes it an ideal choice for advertising materials displayed in various environmental conditions.

Q: How does the integrated drying system improve workflow?

A: The combination of IR heating and fan drying rapidly cures prints, preventing smudging and allowing immediate handling, which accelerates production turnaround and facilitates high-volume output.
