UV Laser Marking Machine

Name: UV Laser Marking Machine
Brand: MEHTA CAD CAM SYSTEMS PVT. LTD.
Price: 875000.00 INR
Availability: InStock

Price 875000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 , , Unit

UV Laser Marking Machine Specification

Marking Area
110 x 110 mm (optional up to 200 x 200 mm)

Marking Speed
7000 mm/s

Condition
New

Laser Type
UV Laser

Cooling Mode
Air Cooling

Control Software
EZCAD

Accuracy
0.01 mm

Power
3W / 5W / 10W

Dimensions
750 x 650 x 1400 mm

Net Weight
Around 100 kg

Minimum Character Size
0.2 mm

Applicable Materials
Glass, Ceramic, Plastic, PCB, Metal, Rubber, etc.

Focus Spot Diameter
<20 m

Engraving Depth
Up to 1 mm (depends on material)

Operation Temperature
15C 30C

Supported Formats
BMP, PLT, DST, AI, DXF, etc.

Repetition Frequency
20-200 kHz

Wavelength
355 nm

Power Supply
220V / 50 Hz

Minimum Line Width
0.01 mm

UV Laser Marking Machine Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About UV Laser Marking Machine

UV Laser Marking Machine designed and developed by our company is widely used in various industries for the making of highly finished marks on various types of engineering elements with the help of high-intensity laser to melt engineering materials for the making of highly finished alphanumeric codes. The offered semi-automated industrial unit is equipped with a computer control system that makes it easier for a single operator to operate this machine. Buy from us this UV Laser Marking Machine at a reasonable and low price range.

The 5W UV Laser Marking Machine is a fast and easy substractive manufacturing method where a laser beam is employed to modify the surface of any desired object. Using this method, images can be etched on a material of your choice, which makes it more effective as opposed to traditional engraving methods. The laser generates high heat that vaporizes the matter and exposes cavities that gives shape to the final image. The material gets eliminated with each pulse of the laser. Besides, depending on the times the laser beam is made to pass the material, the depth of the marks can be easily controlled on any kind of metal using 5W UV Laser Marking Machine.

Technical Specification of UV Laser Marking Machine:

Model Name/Number	Mehta/Evan
Usage/Application	Precise And sharp Marking On Non metal
Marking Speed Capacity	7000 mm/s
Power	3w
Offering Laser	Non Metal
Marking Depth	upto 0.3mm
Voltage	230 Volts
Automation Grade	Semi-Automatic

High Precision and Versatility

This UV Laser Marking Machine stands out for its ability to create extremely fine lines and characters on a vast range of materials. It offers flexibility in application, from intricate electronics components to robust metal products, making it ideal for manufacturers seeking precise and permanent markings.

Easy Operation and Integration

Outfitted with CNC capabilities and EZCAD software, the machine streamlines workflow and supports various file formats like BMP, PLT, DST, AI, and DXF. Its user-friendly interface allows quick setup and smooth operation, ensuring easy adoption into existing manufacturing processes.

Efficient Air Cooling System

The advanced air cooling design effectively manages heat, helping the system maintain optimal performance within temperatures of 15C to 30C. This ensures stable operation and longevity while simplifying maintenance, eliminating the complexities associated with water cooling units.

FAQ's of UV Laser Marking Machine:

Q: How does the UV Laser Marking Machine achieve such high marking accuracy?

A: The UV Laser Marking Machine utilizes a 355 nm wavelength UV laser and a finely focused spot diameter of less than 20 m, enabling precise markings down to a line width of 0.01 mm and character sizes of 0.2 mm. Advanced CNC control and EZCAD software ensure excellent accuracy (0.01 mm) in every operation.

Q: What materials can be marked with this UV laser machine?

A: This machine is engineered to mark a wide variety of materials, including glass, ceramics, plastics, PCBs, metals, rubber, and more. Its versatile performance makes it suitable for applications across electronics, automotive, medical device, and packaging industries.

Q: When is a UV laser marking machine preferred over other laser types?

A: UV laser marking is preferred when high contrast, minimal heat-affected zones, and ultra-fine details are essential. This makes it ideal for micro-marking on sensitive or heat-resistant materials and ensures clear, damage-free results, particularly on plastics, glass, and electronic components.

Q: Where can I integrate this machine within my production line?

A: Due to its compact footprint (750 x 650 x 1400 mm), the machine can be seamlessly integrated into various points on a production line, either as a standalone workstation or within automated CNC workflows. Its flexibility supports both batch and continuous manufacturing setups.

Q: What is the marking process with this UV laser system?

A: The marking process involves importing your design into EZCAD software in supported formats (BMP, PLT, DST, AI, DXF, etc.), adjusting the settings, and allowing the UV laser to precisely engrave or mark the material surface according to your specifications.

Q: What are the benefits of air cooling in this machine?

A: Air cooling in this machine simplifies maintenance, reduces system complexity, and ensures the equipment operates efficiently within 15C-30C. This reliable cooling method extends the machine's lifespan and reduces downtime compared to traditional water-cooled systems.

Q: How fast and deep can this UV laser engrave, and what is the marking area?

A: The machine achieves impressive marking speeds of up to 7000 mm/s and can engrave to a depth of up to 1 mm depending on the material. The standard marking area is 110 x 110 mm, with optional upgrades to 200 x 200 mm for larger applications.
