UV Flat Bed Printer RasterJet RJ 1016

Name: UV Flat Bed Printer RasterJet RJ 1016
Brand: MEHTA CAD CAM SYSTEMS PVT. LTD.
Price: 1225000.00 INR
Availability: InStock

Price 1225000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 , , Unit

UV Flat Bed Printer RasterJet RJ 1016 Specification

Processor Type
High speed industrial controller

Print Technology
UV LED inkjet

Function
Flat bed UV printing

Weight
Approx. 450 kg

Noise Level
< 65 dB

Interface
USB 2.0 / Ethernet

Cabinet Material
Heavy duty steel

Print Speed
Up to 12 sqm/hr (color), up to 16 sqm/hr (mono)

Processor Speed
Industrial microcontroller, optimized for printing tasks

Working Temperature
18C - 30C

Features
White ink support, anti-static system, vacuum bed, multi-layer printing, height detection

Humidity %
20% - 80% RH

Capacity
Supports media up to 100 mm thickness

Usage & Applications
Acrylic, glass, wood, MDF, PVC, ceramic tiles, metal, leather, and more

Power Supply
Single phase, 220V

Condition
New

Material
Metal frame, automotive grade components

Dimensions
Approx. 1600 mm x 1200 mm x 1100 mm

Gross Power
3000 W

Voltage
AC 220V, 50/60Hz

Automatic Grade
Automatic

Color Print Speed
Up to 12 sqm/hr

Black Print Speed
Up to 16 sqm/hr

Maximum Paper Size
1000 mm x 1600 mm

Maximum Resolution
1440 dpi

Use
UV flat bed printing on various materials

Alignment System
Automatic media alignment & registration

Media Thickness
Up to 100 mm

Print Head Technology
Epson DX8/Epson i3200 / Ricoh Gen5 (model dependent)

Safety Systems
Emergency stop, overload protection, ink alarm

Color Configuration
CMYK + White + Varnish (optional)

Operating System
Windows 7/8/10

Ink Type
UV-curable LED ink

Curing System
Dual LED lamp with adjustable power

Print Mode
Unidirectional & bidirectional print support

Maintenance System
Automatic cleaning and capping station

Image Format Support
BMP, TIF, JPG, PDF, etc.

Software Compatibility
Compatible with major RIP software (Photoprint, Maintop, Wasatch)

UV Flat Bed Printer RasterJet RJ 1016 Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About UV Flat Bed Printer RasterJet RJ 1016

Technical Specification ofUV Flat Bed Printer RasterJet:

Country of Origin	Made in India
Model/Type	RJ 1016
Usage/Application	Printing
Brand/Make	Raster Jet
Capacity	100cm (W) x 160cm (L)
Weight	510 kg
Printing Technology	Uv Inkjet
Printing Material	Arcylic, Glass, MDF, PVC, Metals, Tiles, Wood Etc
Driven Type	AC Servo Motor
Max Print Area	1000 x 1600 mm
Ink Type	UV LED Curable
Power Requirement	AC 220 Volts
Print Head	Ricoh GH2220
Print Technology	UV
Resolution	635 x 900 DPI, 635 x 1200 DPI, 635 x 1800 DPI
Speed	Upto 130 SqFt / Hr
Thickness	Upto 75 mm
Voltage	AC 220 Volts

Technology and all electronics are from Switzerland.

High speed than any regular UV Printers, thanks to its electronics & Yaskawa AC Servo Motor.
Printer is provided with PC hardware with LINUX based OS Ubuntu which makes virus free, even large file can be process at high speed.
Back to back printing (3 layers) in single command is possible (CMYK + White + CMYK).
Metallic linear Encoder on both Axis (X, Y) gives high precision printing.
Z-Axis Movement up to 300 mm, One can print on 300 mm thickness media.
RasterJet UV printers are equipped with latest silent LM guide.
All AC Servo motors and drives are from Yaskawa (Japan), for long life, trouble and maintenance free operation.
Smart printing technology enable to higher productivity.
White ink recirculation system is preventing to sedimentations of ink pigment.

Advanced Print Head Technology

The RasterJet RJ 1016 offers users the choice between Epson DX8, Epson i3200, or Ricoh Gen5 print heads, ensuring exceptional clarity and speed tailored to specific production needs. This flexibility allows businesses to optimize printing based on required resolution and throughput.

High Versatility for Media and Applications

Capable of handling media up to 100 mm thick, the RJ 1016 prints effortlessly on wood, acrylic, glass, metal, and more. The inclusion of white and optional varnish inks enables creative applications for signage, packaging, and promotional items with outstanding durability and visual impact.

FAQs of UV Flat Bed Printer RasterJet RJ 1016:

Q: How does the RasterJet RJ 1016 ensure accurate media alignment during printing?

A: The printer features an automatic media alignment and registration system, which precisely positions substrates before printing to maintain image fidelity and reduce manual setup errors.

Q: What types of ink are used in the RJ 1016 UV Flat Bed Printer, and what are their advantages?

A: This printer utilizes UV-curable LED ink, renowned for its rapid curing, robust adhesion to various substrates, and resistance to fading, scratches, and chemicals, making prints suitable for indoor and outdoor use.

Q: When should I use the white or varnish ink options offered by the printer?

A: White ink is ideal for printing on non-white or transparent media, providing vibrant color contrast. Varnish can be applied optionally to add glossy effects or enhance durability of printed images, perfect for premium finishes or high-touch applications.

Q: Where can the RJ 1016 UV Flat Bed Printer be effectively used?

A: It is widely used in commercial printing, signage manufacturing, promotional item production, and packaging industries, particularly suited to businesses in India seeking reliable, high-quality results on diverse substrates.

Q: What is the maintenance process for the RJ 1016 printer?

A: The RJ 1016 is equipped with an automatic cleaning and capping station, helping maintain print head health and minimize manual intervention. This ensures consistent print quality and extends the longevity of critical components.

Q: Which image formats and software does the printer support?

A: The printer is compatible with major RIP software such as Photoprint, Maintop, and Wasatch, and supports BMP, TIF, JPG, and PDF formats, offering flexibility for different workflow requirements.

Q: What safety features are included for operator protection and print reliability?

A: Key safety systems include emergency stop, overload protection, and ink alarm mechanisms to prevent operational issues and ensure safe use in demanding production environments.
