CNC Wooden Pattern Making Machine

CNC Wooden Pattern Making Machine

1500000.00 INR/Unit

Product Details:


Price And Quantity

  • 1 Unit
  • 1500000.00 INR/Unit

Trade Information

  • 10 Unit Per Month
  • 1 Months

Product Description

CNC Wooden Pattern Making Machine is a semi-automated industrial unit that is commonly used in furniture making industries for the making of highly finished intricate designs on various types of wood. It is equipped with top-quality CNC-controlled drives that ensure faster machining and high precision machining. The structural frame of this unit is fabricated by using premium-quality materials that offer high durability and robustness to prevent damages due to machining. CNC Wooden Pattern Making Machine offered by us can be delivered to our customers as per their demands.

Product details



Automatic Grade


Job Material




We are offering CNC Wooden Pattern Making Machine to our client.

Technical Specification




Travelling Area(X, Y, Z)

1200 x 1200 x 600 mm

1300 x 2500 x 600 mm

Working Area

1200 x 1200 x 500 mm

1300 x 2500 x 500 mm


X and Y Axis Transmit by Rack & Pinion with timing pulley & belt mechanism

Table Structure

Rigid Steel Frame Structure

Spindle Power

6 KW, Air Cooled (HSD Italian Spindle)

13.5 KW, Air Cooled (HSD Italian Spindle)

Spindle Speed

18000 RPM

Maximum Travelling Speed

25 mtr/min

Maximum Working Speed

15 mtr/min

Driving System

Yaskawa AC Servo Motor 5.39 nm Torque

Working Voltage

AC 440 /3PH/50hz

Command Language

G Code- (*.tab *.NC)

Operating System

NC Studio Software with PCI controller

Above specifications are subject to change without prior notice
