GX 1325 ATC CNC Engraving Machine

Name: GX 1325 ATC CNC Engraving Machine
Brand: MEHTA CAD CAM SYSTEMS PVT. LTD.
Price: 1800000.00 INR
Availability: InStock

Price 1800000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 , , Unit

GX 1325 ATC CNC Engraving Machine Specification

Production Capacity
8-12 sheets/hour

Control System
NC Studio / DSP / Syntec

Lubricating System
Automatic

Power Rating
6.0 kW

WorkingSpeed
0-20,000 mm/min

Noise Level
75 dB

Model No
GX 1325 ATC

Frame Type
Heavy Duty Welded Frame

Motor Power
Servo Motor 1.8 Kw

Connectivity Options
USB, Ethernet

Plastic Processed
PVC, Acrylic

Cooling System
Water Cooling

Machine Type
CNC Router Engraving Machine

Features
Automatic Tool Change, High Speed, High Precision

Drive
Rack & Pinion Drive

Accuracy
0.05 mm

Operating Temperature
5C - 40C

Voltage
380V/50Hz

Frequency
50 Hz

Product Type
ATC CNC Engraving Machine

Technology
Automatic Tool Changer (ATC)

Power Source
Electric

Operating Type
Automatic

Power
6.0 kW

Pressure
Atmospheric

Surface Treatment
Powder Coated

Dimension (L*W*H)
1300 mm x 2500 mm x 1850 mm

Weight (kg)
1200 kg

Color
Blue & White

Usage & Applications
Wood, MDF, PVC, Acrylic, Aluminum composite panel engraving & cutting

GX 1325 ATC CNC Engraving Machine Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About GX 1325 ATC CNC Engraving Machine

Product details

Automatic tool changer	BT30,ISO30,8 positions
Automatic Grade	Automatic
Features	Self-Lubrication System,Spindle Cooling System,Workpiece Cooling System,Tool Offset Sensor
Brand	Mehta
Model Number	GX - 1325V ATC
Spindle Speed	24000 RPM
Weight	2000 kg
Working Area	1300 x 2500 x 300 mm
Power Supply	AC440/3PH
Three Axis control motor	AC servo motor [Mitshubishi,Japan]
Spindle	7.5 KW [Optional 10KW 12 KW],HSD Italian
Position Accuracy	0.02 mm
Outer Dimension	2865 x 2560 x 3683 mm
Maximum Traveling Speed	45 mtr/min
Material Holding	Vacuum Combined T-slot
Controller	High speed NK260 integrated system
Collet	ER32,Max 16mm Dia tool

Specification

Models	GX - 1530V ATC
Outer Dimension	3065 x 3660 x 3683 mm
Working Area (X, Y, Z)	1500 x 3000 x 300 mm
Weight	2500 kg [Approx]

Advanced CNC Performance

The GX 1325 ATC CNC Engraving Machine brings a new level of automation and speed to detailed engraving and cutting. With its automatic tool changer, operators can switch between 8-12 tools effortlessly, boosting both productivity and precision. Supported by a high-speed spindle and robust servo motor, this machine delivers consistent, accurate results across a range of materials including wood, PVC, and composite panels.

Versatile Workholding and Applications

Designed with a dual vacuum and T-slot table, the GX 1325 ATC securely accommodates materials of varying sizes and thicknesses. Its large working area (1300 x 2500 x 200 mm) paired with a heavy-duty welded frame makes it suitable for demanding production environments. From complex signage to custom furniture components, this CNC engraving machine covers a broad spectrum of industrial and commercial applications.

User-friendly Operation and Connectivity

The machine integrates an intuitive LCD controller and supports operational languages in English and Chinese, making setup and management straightforward for global users. It offers flexible connectivity through USB and Ethernet, and is compatible with widely-used design and CNC software like ArtCAM, Type3, Ucancam, and Aspire, ensuring seamless workflow integration and easy file management.

FAQs of GX 1325 ATC CNC Engraving Machine:

Q: How does the automatic tool changer (ATC) function on the GX 1325 ATC CNC Engraving Machine?

A: The ATC system automatically swaps between 8-12 different tools without manual intervention, streamlining the production process and reducing downtime. This is particularly useful when projects require multiple tool operations, ensuring continuous, efficient workflow.

Q: What materials can the GX 1325 ATC handle, and what are its primary applications?

A: This machine is designed for engraving and cutting wood, MDF, PVC, acrylic, and aluminum composite panels. Its versatility makes it suitable for furniture manufacturing, signage production, decorative panel work, and other applications involving layered or synthetic materials.

Q: When should the vacuum or T-slot feature of the combined table be used?

A: Vacuum clamping is best for securing flat, large sheets rapidly, ideal for quick setup and thin materials. T-slot clamping provides adjustable and strong holding for irregularly shaped or thick items, offering flexibility depending on your project requirements.

Q: Where is the GX 1325 ATC best installed for optimal performance?

A: This CNC machine is designed for floor-mounted installation in well-ventilated workshops or production floors with stable atmospheric pressure, operating temperatures between 5C and 40C, and humidity between 30%-75%. Adequate space for material handling will further enhance operational efficiency.

Q: What is the process for loading files and starting an engraving job on the GX 1325 ATC?

A: Design files can be created in software such as ArtCAM, Aspire, or Ucancam, saved in compatible formats (G-code, BMP, DXF, PLT, AI, etc.), and transferred via USB or Ethernet. Once loaded, select the desired toolpaths and materials, set up your clamping method, then calibrate the machine using the LCD controller to begin the engraving operation.

Q: How does the machine ensure high accuracy and repeatability during operation?

A: The GX 1325 features Hiwin linear square guides, ball screw transmission for the Z-axis, high torque servo motors, and an automatic lubrication system, delivering repeatability of 0.02 mm and overall machining accuracy of 0.05 mm. This construction ensures reliable, precise cuts and engravings batch after batch.

Q: What are the main benefits for workshops or factories investing in the GX 1325 ATC?

A: Key advantages include higher production capacity (8-12 sheets/hour), minimized manual labor due to ATC, robust performance across many materials, fast working speeds, and enhanced safety features like the emergency stop. Its industrial-grade build and compatibility with popular CAD/CAM software streamline complex jobs, boosting overall efficiency and yield.
