LX1325 CNC Engraving Machine

Name: LX1325 CNC Engraving Machine
Brand: MEHTA CAD CAM SYSTEMS PVT. LTD.
Price: 600000.00 INR
Availability: InStock

Price 600000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

LX1325 CNC Engraving Machine Specification

Lubricating System
Manual Lubrication

Features
High Precision, Stable Structure, Easy Operation

Connectivity Options
USB, Offline Controller

Accuracy
0.05 mm

Voltage
380V / 220V (Optional)

Production Capacity
Continuously Operable

Machine Type
CNC Router/Engraver

Noise Level
<75 dB

Operating Temperature
0C - 45C

Frame Type
Heavy Duty Welded Steel Frame

Power Rating
3.0 kW

Model No
LX1325

Motor Power
Stepper Motor

Drive
Rack & Pinion

Frequency
50/60 Hz

Control System
DSP Control System

Cooling System
Water Cooling

Plastic Processed
Acrylic, PVC

Product Type
CNC Engraving Machine

Technology
CNC (Computer Numerical Control)

Power Source
Electric

Operating Type
Automatic

Power
3.0 kW

Surface Treatment
Painted

Dimension (L*W*H)
3200 x 2100 x 1800 mm

Weight (kg)
1200 kg

Color
Blue/White

Usage & Applications
Wood, MDF, Acrylic, PVC, Soft Metals Engraving and Cutting

Supported File Formats
G-code, HPGL, PLT, DXF, BMP, etc.

Working Speed
0-25,000 mm/min

Table Structure
Vacuum and T-slot Combined

Transmission System
XY Axis: Rack and Pinion, Z Axis: Ball Screw

Safety Features
Emergency Stop, Limit Protection

Resolution
0.01 mm

Software Compatibility
ArtCAM, Type3, UG, Pro/E, CorelDraw, AutoCAD

Working Area
1300 x 2500 mm

Tool Changing
Manual

Max Traveling Speed
35,000 mm/min

Z-axis Travel
200 mm

Spindle Speed
0-24,000 rpm

LX1325 CNC Engraving Machine Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About LX1325 CNC Engraving Machine

Product details:

Cutting Tool Diameter	3 to 20 mm
Automatic Grade	Automatic
Applicable Materials	Wooden
Brand	Mehta
Model Number	LX - 1325
Spindle Speed	18000 RPM
Weight	875 Kg
Working Area	1300 x 2500 x 200 mm
Operating System	DSP - Hand Held Controller
Power Supply	AC 420V/3PH
Spindle	6 KW Air Cooled (HSD Italian)
Repeated Location	0.025 mm
Outer Dimension	2002 x 3150 x 1541 mm
Maximum Traveling Speed	20 mtr/min
Driving System	Stepper Motor
Distance between Bed and Gentry	200 mm

Technical Specification

Models	LX - 1530
Outer Dimension	2200 x 3650 x 1541 mm
Working Area (X, Y, Z)	1500 x 3000 x 200 mm
Spindle	6 KW Air Cooled (HSD Italian)
Spindle Speed	18000 RPM
Distance between Bed and Gentry	200 mm
Maximum Traveling Speed	20 mtr/min
Cutting Tool Diameter	3 to 20 mm
Repeated Location	0.025 mm
Operating System	DSP - Hand Held Controller
Driving System	Stepper Motor
Weight	1000 Kg Approx
Power Supply	AC 420V/3PH

Powerful Engraving Performance

The LX1325 CNC Engraving Machine delivers remarkable power and precision, handling diverse materials with a max traveling speed of 35,000 mm/min. Its advanced transmission system includes a rack and pinion for the XY axis and ball screw for the Z axis, ensuring stable and reliable movement. Ideal for industries requiring consistent results, this machine streamlines bulk and custom engraving tasks efficiently.

Versatile Table Structure

Combining vacuum and T-slot systems, the LX1325 ensures superior material holding during engraving and cutting processes. This flexibility enhances safety and allows users to work with various material sizes, minimizing slippage and supporting intricate projects. The robust table design is particularly useful for high-volume manufacturing and customized applications.

Broad Software Compatibility

Seamlessly integrating with industry-standard software like ArtCAM, Type3, UG, Pro/E, CorelDraw, and AutoCAD, the LX1325 CNC makes it easy to work with different design files and formats, including G-code, HPGL, PLT, DXF, and BMP. This compatibility allows for smooth workflow integration, whether for mass production or individual creative work.

FAQs of LX1325 CNC Engraving Machine:

Q: How does the LX1325 CNC Engraving Machine ensure precise results during operation?

A: The LX1325 provides a resolution of 0.01 mm, using a rack and pinion transmission for the XY axis and a ball screw for the Z axis. These components guarantee accurate, smooth movements that are essential for intricate engraving tasks.

Q: What types of files and design software can I use with the LX1325 CNC Engraving Machine?

A: You can use files such as G-code, HPGL, PLT, DXF, and BMP. Supported design software includes ArtCAM, Type3, UG, Pro/E, CorelDraw, and AutoCAD, making the machine versatile for various design workflows.

Q: When should I use the vacuum versus T-slot feature on the worktable?

A: The vacuum feature is ideal for flat panels requiring secure, broad contact, while the T-slot is suited for irregular shapes or thicker materials needing customized clamping. Choosing between them depends on your projects requirements for stability and holding force.

Q: Where can I source the LX1325 CNC Engraving Machine in India?

A: As an exporter, importer, manufacturer, and supplier, the LX1325 is readily available from authorized distributors and direct manufacturers throughout India. Local support ensures timely delivery and efficient after-sales service.

Q: What is the process for changing tools on the LX1325 CNC?

A: Tool changing on this machine is manual, allowing operators to safely and accurately switch between different cutting or engraving tools as needed, ensuring flexibility for various tasks.

Q: How can the LX1325s safety features benefit industrial operators?

A: Equipped with emergency stop and limit protection, the LX1325 prioritizes workplace safety. These features protect operators and prevent potential machine damage during unexpected incidents, fostering a secure manufacturing environment.

Q: What are the main advantages of using the LX1325 CNC for medium- and large-scale production?

A: Its large working area, high spindle speed, fast traveling and working speeds, robust table structure, and versatile software compatibility enable efficient processing of large volumes and customized designs, maximizing productivity for manufacturers and suppliers.
