Engraver Machine

Name: Engraver Machine
Brand: MEHTA CAD CAM SYSTEMS PVT. LTD.
Price: 275000.00 INR
Availability: InStock

Price 275000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Engraver Machine Specification

Frequency
50 Hz

Voltage
220V AC

Motor Power
Stepper Motor, 57 Series

Cooling System
Air Cooled

Features
High Precision, Portable, User-friendly Operation, Low Maintenance

Plastic Processed
ABS, Acrylic

Accuracy
0.05 mm

Frame Type
Rigid Alloy Frame

Connectivity Options
USB, RS232

Lubricating System
Semi-automatic Grease Lubrication

Noise Level
<70 dB

Drive
Belt Drive

Operating Temperature
5C - 40C

Model No
EM-350

Machine Type
Engraver

Control System
Digital Controller Panel

Power Rating
150W

Production Capacity
FlexibleBased on Operation

Product Type
Engraving Machine

Technology
CNC, Laser, Mechanical

Power Source
Electric

Operating Type
Semi-Automatic

Power
150W (typical)

Pressure
Manual Operation, Not Applicable

Surface Treatment
Anodized/Coated Metal Frame

Dimension (L*W*H)
400 x 350 x 250 mm

Weight (kg)
12 kg

Color
Silver/Grey

Usage & Applications
Metal, Plastic, Glass, and Wood Engraving; Nameplate Fabrication;

Engraver Machine Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About Engraver Machine

Engraver Machine is a premium-class industrial unit that is designed and developed by our team of highly skilled professionals by using advanced electrical drives and heavy engineering materials that results in high working efficiency and robustness. This machining unit is capable to make highly finished intricate designs on various types of metallic as well as non-metallic substances with the help of a high-intensity laser beam. Customers can get this high-speed Engraver Machine from us at a reasonable and low price range with an assurance of fast and safe delivery.

Product details

Country of Origin	Made in India
Marking Speed Capacity	10000 mm/s
Operation Mode	Automatic
Laser Type	Fiber Laser
Voltage	220V
Model Name/Number	Evan
Brand	Mehta

Technical Specification

Model No	EVAN-10	EVAN-20	EVAN-30	EVAN-50	ETAN-100
Laser average output power	10 W	20 W	30 W	50 W	100 W
Wavelength	1064 nm
Power Adjustment	0 to 100 %
Cooling	Air Cooled
Min. Line Width	Min. 0.03 mm (Depend on Material)
Max. Speed	Max. 10000 mm/s (Max. Linear Speed)
Marking Depth	0.010.3mm (Depends on Material)
Min Character Height	0.5mm
Marking Range	145 mm X 145 mm(Standard) Optional : 175 X 175 mm 300 X 300 mm
Supporting Format	Support PLT, DXF, BMP File etc., Using SHX TTF Character Storage Directly
Marking Area	145 x 145 (standard) 175 x 175 / 300 x 300 (Optical)
Single Pulse Energy (mj)	0.5 to 20KHz	1 to 20KHz	1 to 30KHz	1 to50 KHz	2.0 to 50 KHz
Repetition Frequency Range	20-80 KHz	20-80 KHz	30-80 KHz	50-100 KHz	50-100 KHz
Output Power Stability	< 3%
Beam Quality(M2 )	< 1.5		< 1.8		< 2.0
Pulse Width(ns)	< 100 to 20 KHz	< 130 to 20 KHz			< 200 to 50 KHz
Power Supply	DC 24 Volt				AC 220 Volt
Max Power Consumption	120 Watt	200 Watt	250 Watt	300 Watt	500 Watt
Specifications are subject to change without notice

Exceptional Precision and Versatility

Engineered for consistent accuracy, the EM-350 engraver delivers finely detailed results on a variety of materials including metal, wood, glass, and plastic. Its 0.2 mm minimum line width allows for high-resolution patterns, making it perfect for intricate artwork or precise nameplate fabrication. The 300 x 200 mm engraving area suits both small batches and one-off projects, giving users the flexibility to take on various jobs.

User-Friendly Digital Controls and Fast Workflow

Featuring a digital controller panel and seamless input via USB or RS232, the EM-350 ensures effortless file transfer and setup. Users can work with popular software like CorelDRAW, AutoCAD, or CAD/CAM programs, enabling quick adaptation into existing workflows. Its 512 KB buffer and up to 7200 mm/min working speed boost productivity, making it a smart choice for fast-paced environments.

Robust Construction, Safe Operation, and Easy Maintenance

Built with a rigid anodized frame and designed for low-maintenance, quiet operation (<70 dB), the EM-350 meets CE safety standards. Air-cooled with a semi-automatic grease lubrication system, it supports continuous operation. Its compact 400 x 350 x 250 mm benchtop profile and manageable 12 kg weight suit businesses with limited workspace while maintaining premium durability and safety.

FAQ's of Engraver Machine:

Q: How do I set up and operate the EM-350 engraver machine?

A: Setting up the EM-350 involves placing it on a stable benchtop, connecting it to a 220V AC power supply, and interfacing via USB or RS232. Load your design files (NC, BMP, DXF, JPG, or SVG) using compatible software such as CorelDRAW or AutoCAD. Use the digital controller panel to configure parameters like engraving speed and depth, then initiate the engraving process. Onsite or remote technical assistance is available if you need guidance.

Q: What materials and thicknesses can the EM-350 engrave?

A: The EM-350 can engrave metals, plastics (including ABS and acrylic), glass, and wood. Material thickness capability is up to 20 mm, depending on the processed substrate. This versatility makes it suitable for creating nameplates, industrial parts, and customized items across various industries.

Q: When should I use the air cooling and semi-automatic grease lubrication features?

A: The air cooling system operates automatically during use to maintain safe operating temperatures, especially for extended engraving tasks. The semi-automatic grease lubrication should be performed periodically, as indicated in the user manual, to ensure smooth spindle and mechanical component operation for long-term reliability.

Q: Where can I find support or maintenance services for this machine?

A: EM-350 users receive access to both onsite and remote technical assistance, including installation, troubleshooting, and maintenance. Contact the manufacturer or your supplier in India for service scheduling, software updates, or replacement parts to ensure optimal performance.

Q: What is the benefit of the machine's high-precision accuracy and fast working speed?

A: With a 0.05 mm accuracy and up to 7200 mm/min working speed, the EM-350 enables rapid, detailed engraving while maintaining exceptional quality. This leads to improved productivity and reduced turnaround time for both standard and custom projects, making it advantageous for businesses with demanding schedules.

Q: How does the EM-350 ensure user safety during operation?

A: Certified with the CE mark, the EM-350 incorporates safety features such as a robust, rigid alloy frame, controlled digital panel, and an enclosed system design. It operates quietly (<70 dB) and is built with safe electrical and thermal profiles to ensure operator protection throughout use.
