UV FlatBed Printer RasterJet RJ 2513

Name: UV FlatBed Printer RasterJet RJ 2513
Brand: MEHTA CAD CAM SYSTEMS PVT. LTD.
Price: 2200000.00 INR
Availability: InStock

Price 2200000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 , , Unit

UV FlatBed Printer RasterJet RJ 2513 Specification

Print Technology
UV Inkjet Flatbed

Function
Flatbed UV Printing

Features
High precision printheads, White ink support, LED UV curing system, Variable dot printing, Anti-crash sensor

Capacity
Large-sized sheets and rigid media

Working Temperature
20C to 30C

Print Speed
Up to 20 sqm/hr

Processor Speed
1.8 GHz

Processor Type
Dedicated Print Controller

Noise Level
60 dB

Interface
USB 2.0 / Ethernet

Power Supply
Single Phase

Humidity %
20% to 80%

Cabinet Material
Reinforced Sheet Metal

Usage & Applications
Glass, Wood, Acrylic, Metal, Plastic, PVC, Foam Board, Ceramic, Leather, and more

Weight
1000 kg (approx.)

Condition
New

Material
Metal & High-Strength Steel

Dimensions
4200 x 2100 x 1300 mm (L x W x H)

Gross Power
3.5 kW

Voltage
220V 10%, 50/60Hz

Automatic Grade
Automatic

Color Print Speed
20 sqm/hr

Black Print Speed
20 sqm/hr

Maximum Paper Size
2500 x 1300 mm

Maximum Resolution
1440 x 1440 dpi

Use
Industrial, Commercial Printing

Media Thickness
Up to 100 mm

Ink Type
UV Curable Ink (CMYK/White/Varnish)

Alignment System
Auto Media Registration Pins

Vacuum Table
Integrated, adjustable zones

Operating System Compatibility
Windows 7/8/10

Print Head
Industrial-grade, multi-channel

RIP Software
Photoprint / Maintop (Optional)

File Format Support
TIFF, BMP, EPS, JPEG, PDF, etc.

Safety System
Emergency stop buttons and safety sensors

Curing System
LED UV Lamp (Adjustable)

UV FlatBed Printer RasterJet RJ 2513 Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About UV FlatBed Printer RasterJet RJ 2513

The 2000 mm x 3000 mm UV Flatbed Printers are designed to meet the various printing requirements of the industries. It ensures premium quality prints to be used by various industries. For printing and packaging it is highly reliable good performing asset. The 2000 mm x 3000 mm UV Flatbed Printer offers bright colors on vast arrays of materials including three dimensional thick materials. It can print lager areas in high speed and you can avail these printers at market leading price.

Product details

Country of Origin	Made in India
Model/Type	RJ 2513
Features	Panasonic Servo Motor
Usage/Application	Printing
Brand/Make	Raster Jet
Printer Weight	1150 Kgs
Capacity	2500mm (W) x 1300mm (L)
Power Supply	220 Volts
Printing Direction	Uni & BI Directional
Printing Resolution	635 x 900 Dpi, 635 x 1200 Dpi, 635 x 1800 Dpi
Printing Speed	240 SqFt / Hr
Printing Technology	Uv Inkjet
Production Mode	240 SqFt / Hr
Printhead	Ricoh GEN5
Material Thickness	Upto 100 mm Thick
Ink Type	UV LED Curable
Maximum Print Width	2500 mm
Maximum Length	1300 mm

Technical Specification

Model	RJ 2513
Print head	3 Ricoh Gen 5 Industrial Print head (Up to 8 Optional)
Maximum Print Size	2500mm (L) x 1300mm (W)
Printing Resolution	720x1200 dpi
Printing Direction	Uni and Bi-Direction
Printing Technology	Variable Dot Printing (Grey Scale Printing)
Media Max. Thickness	10cm
Ink type	UV LED Curable Inks
Ink Color	C,M,Y,K, White (Standard), Lc, Lm, Varnish (Optional)
Ink Capacity	1000ml Bottal
Ink Supply System	Negative Pressure System (NPS) with Automatic Ink Supply
UV Technology	Dual UV LED Lamp
RIP	Color Gate
Interface	USB 2.0
Power Requirements	AC 100-110 Volt / 220-240 V, 50/60Hz
Assembled Dimensions (W x H x D)	440cm x 220cm x 140cm
Net Weight	760kgs

Printing Speed

Resolution	720x900dpi 720x1200dpi	720x900dpi 720x1200dpi	720x900dpi 720x1200dpi
Number Of Pass	6 Pass	8 Pass	12 Pass
Direction	Bi-Direction	Bi-Direction	Bi-Direction
Speed	14 sq. m/hr	12 sq. m/hr	8 sq. m/hr

High-Performance UV Flatbed Printing

The RasterJet RJ 2513 UV FlatBed Printer combines industrial-grade precision with user-friendly automation. It boasts a 1440 x 1440 dpi maximum resolution and supports large sheets up to 2500 x 1300 mm, accommodating a wide range of rigid media. Engineered for demanding environments, its dedicated print controller and variable dot technology ensure sharp, vibrant prints every time.

Versatile Applications and Media Support

Designed for flexibility, the RJ 2513 can print on glass, wood, acrylic, metal, plastic, PVC, foam board, ceramic, and leather, making it the perfect solution for industrial decor, signage, and personalized product manufacturing. Its ability to handle material thickness up to 100 mm opens up endless creative possibilities.

Safety and Reliability in Every Print Job

Safety is paramount with this printer, featuring emergency stop buttons, anti-crash sensors, and safety sensors. Its reinforced sheet metal construction ensures durability, while the integrated vacuum table with adjustable zones guarantees precise media handling, so you can focus on productivity without compromises.

FAQ's of UV FlatBed Printer RasterJet RJ 2513:

Q: How does the UV curing system in the RasterJet RJ 2513 benefit my printing process?

A: The adjustable LED UV lamp system ensures fast ink curing, improving print durability and enabling immediate handling of prints. This process not only yields vibrant and long-lasting results but also increases overall productivity by minimizing wait times between jobs.

Q: What types of materials can I print on with the RJ 2513 UV FlatBed Printer?

A: This printer can handle a diverse range of rigid and semi-rigid materials, including glass, wood, acrylic, metal, plastic, PVC, foam board, ceramic, and leather, with media thickness up to 100 mm. This versatility makes it suitable for a wide variety of industrial and commercial printing applications.

Q: When is it recommended to use white ink or varnish in my projects?

A: White ink is ideal for printing on transparent or colored substrates, providing a solid base or added highlights. Varnish is used for special effects, spot finishes, and enhancing image depth. Both features allow for creative results and improved product value.

Q: Where should the RJ 2513 printer be installed for optimal performance?

A: Install the printer in a clean, well-ventilated environment with temperature maintained between 20C to 30C and humidity levels of 20% to 80%. Adequate space for the machine's dimensions (4200 x 2100 x 1300 mm) and safe, stable, single-phase 220V power supply is essential for smooth operation.

Q: What is the process for aligning media on this flatbed printer?

A: The RJ 2513 features automatic media registration pins and an integrated vacuum table with adjustable zones, which help to firmly secure and align your material. This ensures precise placement and consistent print quality with every job.

Q: How does the anti-crash sensor enhance printer safety and longevity?

A: The built-in anti-crash sensor detects obstructions or irregularities on the print bed, stopping the machine to prevent print head damage. This feature helps protect critical components, minimizes downtime, and extends the printer's service life.

Q: What are the primary advantages of using the RJ 2513 for industrial printing?

A: The main benefits include high-speed, high-resolution output up to 20 sqm/hr, compatibility with large and thick materials, support for white and varnish inks, and robust safety and alignment systems. These features ensure efficiency, quality, and flexibility for industrial, commercial, and specialty printing needs.
