UV Flatbed Printer RasterJet RJ 7500

Name: UV Flatbed Printer RasterJet RJ 7500
Brand: MEHTA CAD CAM SYSTEMS PVT. LTD.
Price: 1225000.00 INR
Availability: InStock

Price 1225000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 , , Unit

UV Flatbed Printer RasterJet RJ 7500 Specification

Processor Speed
800 MHz

Working Temperature
18C to 30C

Humidity %
20%-80% (Non-condensing)

Capacity
Handles media up to 100 mm thickness

Power Supply
Single Phase 220V/110V

Function
Flatbed Printing, UV Printing, Color Printing

Usage & Applications
Sign Boards, Glass, Acrylic, Ceramic Tiles, Wood, Metal, PVC Sheets, Customized Gifts

Cabinet Material
Metal Alloy

Print Speed
Up to 15 sqm/hr

Noise Level
65 dB

Interface
USB 2.0, Ethernet

Weight
Approx. 650 kg

Print Technology
UV LED Flatbed Printing

Features
High Precision Printing, Multi-layer Printing, White Ink Support, Fast Curing

Processor Type
ARM-based processor

Condition
New

Material
Stainless Steel, Aluminum Alloy

Dimensions
3560 mm x 1380 mm x 800 mm

Gross Power
3500 W

Voltage
AC 220V 10%, 50/60Hz

Automatic Grade
Automatic

Color Print Speed
12 sqm/hr

Black Print Speed
15 sqm/hr

Maximum Paper Size
2500 mm x 1300 mm

Maximum Resolution
2880 x 1440 dpi

Use
Industrial and Commercial Printing

Maintenance
Automatic Head Cleaning System

Media Handling
Vacuum Table Included

Curing System
Advanced UV LED Lamps

Supported Media Thickness
Up to 100 mm

Rip Software
PhotoPrint, RasterLink Supported

Environmental Compliance
RoHS Compliant

Ink Type
UV Curable Ink

Number of Print Heads
3 (Variable Drop Technology)

Operating System Compatibility
Windows 7/10/11

Data Buffer
2 GB

Printing Colours
CMYK+White+Varnish

Cooling Method
Water Cooling for UV Lamps

Safety Features
Emergency Stop, Overheat Protection

UV Flatbed Printer RasterJet RJ 7500 Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About UV Flatbed Printer RasterJet RJ 7500

With the help of our team of technical experts, we are engaged in manufacturing and supplying outstanding quality 700 mm x 500 mm UV Flatbed Printer. It is manufactured using fine grade materials with the help of ultra modern technology. Our quality inspectors test this printer prior to dispatch from our end to ensure its excellent performance at customer end. In addition, this 700 mm x 500 mm UV Flatbed Printer is used for scanning the goods and items at retail shops and malls.

Technical Specification of UV FlatBed Printer RasterJet RJ 7500:

Display	LED
Usage/Application	Printing
Printer Weight	250 Kgs
Power Supply	220 Volts
Printing Direction	Uni & BI Directional
Printing Resolution	635 x 900 Dpi, 635 x 1200 Dpi, 635 x 1800 Dpi
Printing Speed	60 SqFt / Hr
Printing Technology	Uv Inkjet
Production Mode	60 SqFt / Hr
Printhead	6 Ricoh GH2220
Automation Grade	Automatic
Material Thickness	Upto 300 mm Thick
Ink Type	UV LED Curable
Maximum Print Width	70 cm
Maximum Length	50 cm
Brand/Make	Mehta
Model/Type	RJ 7500

Technology and all electronics are from Switzerland.

High speed than any regular UV Printers, thanks to its electronics & Yaskawa AC Servo Motor.
Printer is provided with PC hardware with LINUX based OS Ubuntu which makes virus free, even large file can be process at high speed.
Back to back printing (3 layers) in single command is possible (CMYK + White + CMYK).
Metallic linear Encoder on both Axis (X, Y) gives high precision printing.
Z-Axis Movement up to 300 mm, One can print on 300 mm thickness media.
RasterJet UV printers are equipped with latest silent LM guide.
All AC Servo motors and drives are from Yaskawa (Japan), for long life, trouble and maintenance free operation.
Smart printing technology enable to higher productivity.
White ink recirculation system is preventing to sedimentations of ink pigment.

Versatile, High-Precision Printing

The RasterJet RJ 7500 stands out for its ability to print vivid images on a variety of substrates including sign boards, glass, acrylic, ceramic tiles, wood, and metal. With a media handling capacity up to 100 mm thickness, high resolution (2880 x 1440 dpi), and fast color print speeds up to 12 sqm/hr, it streamlines production for signage, decor, and custom gift manufacturers.

Advanced Technology & User-Friendly Features

Equipped with variable drop print heads, UV LED curing, automatic head cleaning, and a water-cooling system, the RJ 7500 ensures crisp output, minimal maintenance, and consistent quality. The vacuum table secures materials during printing, while compatibility with PhotoPrint and RasterLink offers seamless workflow integration.

Robust Build & Environmental Compliance

Built from stainless steel and aluminum alloy, the RJ 7500 is both durable and dependable for continuous industrial use. The machine adheres to RoHS standards, ensuring environmentally responsible operation without compromising on power or efficiency.

FAQ's of UV Flatbed Printer RasterJet RJ 7500:

Q: How does the RasterJet RJ 7500 accommodate different media types and thicknesses?

A: The RJ 7500 features a vacuum table that holds substrates firmly and supports media up to 100 mm thick. This flexibility allows for printing on materials like acrylic, ceramic, wood, metal, PVC sheets, and more, making it suitable for various commercial and industrial applications.

Q: What benefits does the UV curable ink and LED curing system provide?

A: UV curable ink, combined with advanced UV LED lamps, ensures instant and durable curing on a wide range of surfaces. This setup offers vibrant, scratch-resistant prints and enables printing on heat-sensitive substrates without warping or damage.

Q: When should the automatic head cleaning system be used?

A: The RJ 7500's automatic head cleaning activates as needed, minimizing operator intervention and ensuring consistent print quality. Regular use of this feature helps prevent clogging and extends the lifespan of the print heads.

Q: What safety features are integrated into the UV Flatbed Printer?

A: For operator security, the RJ 7500 includes an emergency stop button and overheat protection systems. These features help prevent accidents and equipment damage during intensive production cycles.

Q: How do I manage and process print jobs with the RJ 7500?

A: The printer is compatible with industry-standard RIP software, including PhotoPrint and RasterLink. This allows for efficient job management, color control, and workflow automation, ensuring high-quality output on every project.

Q: Where is this printer suitable for use?

A: The RJ 7500 is ideal for businesses engaged in the production of signage, decor, promotional items, and customized gifts. Its robust build and versatile media compatibility support demanding environments in manufacturing, export, and supply within India.

Q: What are the main advantages of multi-layer and white ink printing?

A: Multi-layer and white ink functions enable multi-dimensional effects, such as printing opaque images on transparent or colored materials and creating tactile visuals or highlights. These capabilities expand design possibilities and product differentiation.
