Fiber Laser Metal Cutting Machine Gloria ZX 1530 CTC

Send Inquiry

Request To Call Back

Fiber Laser Metal Cutting Machine Gloria ZX 1530 CTC

Name: Fiber Laser Metal Cutting Machine Gloria ZX 1530 CTC
Brand: MEHTA CAD CAM SYSTEMS PVT. LTD.
Price: 6500000.00 INR
Availability: InStock

Price 6500000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 , , Unit

Fiber Laser Metal Cutting Machine Gloria ZX 1530 CTC Specification

Features
High cutting speed, low maintenance, eco-friendly, cost-effective operation

Operating Temperature
0C to 40C

Power Rating
AC 3-Phase 380V 50Hz

Connectivity Options
USB, LAN, Ethernet

Model No
ZX 1530 CTC

Machine Type
Metal Sheet & Tube Cutting

Frequency
50Hz

Drive
Dual Drive Gantry System

Voltage
380V

Accuracy
0.02 mm

Control System
CNC with Touchscreen Interface

Lubricating System
Centralized Automatic Lubrication

Noise Level
<75 dB

Frame Type
Heavy-Duty Welded Frame

Motor Power
Servo Motor: 1.5 kW

Production Capacity
Up to 600 kg/hour

Cooling System
Water Chiller

Product Type
Fiber Laser Metal Cutting Machine

Technology
Fiber Laser Cutting

Power Source
Electric

Operating Type
Automatic

Power
1000 W - 6000 W (Customizable)

Pressure
Optimized for high precision, not pressure-based

Surface Treatment
Laser Cut Finish

Dimension (L*W*H)
4500 mm x 2200 mm x 1700 mm

Weight (kg)
Approx. 2000 kg

Color
Industrial Grey with Red Highlights

Usage & Applications
Sheet metal fabrication, automotive, electronics, construction, signage

Operator Display
15-inch Color Touchscreen

Working Table
Exchangeable Dual Table System

Environmental Requirement
Dust Proofed, Anti-Vibration Foundation Recommended

Repeatability
0.03 mm

Positioning Speed
100 m/min

Assist Gas
Oxygen, Nitrogen, Air

Laser Lifetime
100,000 Hours (Typical)

Cutting Area
1500 mm x 3000 mm

Electricity Consumption
10 16 kW/h (Depending on configuration)

Laser Type
IPG / Raycus Fiber Laser Source

Maintenance Interval
Low, Scheduled as per operating hours

Maximum Material Thickness
Up to 18 mm (Mild Steel), 10 mm (Stainless Steel), 8 mm (Aluminum)

Interface Language
Multi-language (English, Hindi and more)

Table Load Capacity
Max. 900 kg

Safety Systems
Full Enclosure, Emergency Stop, Protective Window

Software Supported
CypCut, AutoCAD, CorelDRAW Compatible

Fiber Laser Metal Cutting Machine Gloria ZX 1530 CTC Trade Information

Minimum Order Quantity
1 , , Unit

Supply Ability
10 Units Per Month

Delivery Time
1 Months

About Fiber Laser Metal Cutting Machine Gloria ZX 1530 CTC

Product details

Condition	New
Model Name/Number	GLORIA-ZX 1530 CTC
Model	GLORIA-ZX 1530 CTC
Laser Power	3000W, 4000W
Machine Type	Laser
Autofocus	Yes
Brand	Mehta
Cutting Material	Mild Steel
Automatic Grade	Automatic
Usage/Application	Industrial

Technical Specification

Model	GLORIA-ZX 1530 CTC
Working Area	5 feet X 10 feet
Laser Source	3000 / 4000 Watt
Laser Type	IPG / Raycus
Laser Wavelength	1080 nm
Cutting Head	RAYTOOLS
Max. Cutting Speed	60 m/min
Max. Traveling Speed	140 m/min
Position Accuracy	< 0.04 mm
Minimum Line Width	< 0.12 mm
Cooling System	Water Cooling
Drives & Control	AC Servo Motor
Working Voltage	AC 420V
Weightage	6.5 ton

High-Precision Metal Cutting Made Simple

The ZX 1530 CTC's dual-drive gantry and servo motor ensure rapid and precise movement, achieving repeatability within 0.03 mm. With up to 600 kg/hour processing capacity and a large 1500 mm x 3000 mm workspace, this machine meets industrial needs in sheet metal fabrication, electronics, and construction. Its intuitive 15-inch color touchscreen and multi-language interface streamline operation for both new and experienced users.

Efficient and Safe Operation

Safety and maintenance are key focuses in the ZX 1530 CTC. A full enclosure, emergency stop system, and protective viewing window provide a secure working environment. The water chiller and centralized automatic lubrication reduce operational downtime. Eco-friendly features, low electricity consumption, and noise levels below 75 dB contribute to a user-friendly and cost-effective production process.

FAQ's of Fiber Laser Metal Cutting Machine Gloria ZX 1530 CTC:

Q: How does the exchangeable dual table system benefit daily production?

A: The exchangeable dual table system allows you to load and unload materials simultaneously with cutting, significantly minimizing downtime and boosting overall productivity, especially in high-volume operations.

Q: What materials and maximum thicknesses can this machine cut?

A: The ZX 1530 CTC can process mild steel up to 18 mm, stainless steel up to 10 mm, and aluminum up to 8 mm thick, making it highly versatile for various metal fabrication tasks.

Q: When should regular maintenance be scheduled for optimal performance?

A: Maintenance intervals are low and depend on operating hours. The centralized automatic lubrication system and robust build mean minimal and scheduled maintenance, ensuring reliable performance with minimal downtime.

Q: Where can I use the Gloria ZX 1530 CTC machine?

A: This laser cutting machine is ideal for use in factories, metal workshops, and manufacturing units involved in the production of automotive parts, electronic enclosures, construction materials, signage, and general metal sheet and tube fabrication.

Q: What process does the machine use for cutting metal?

A: The machine uses advanced fiber laser technology (IPG or Raycus source) guided by a CNC system. This process involves efficiently focusing laser light to achieve precise, high-speed cuts on sheet and tube metals using oxygen, nitrogen, or air as assist gases.

Q: How user-friendly is the control system and software support?

A: The ZX 1530 CTC features a 15-inch color touchscreen with a multi-language interface, making control straightforward. It supports industry-standard software like CypCut, AutoCAD, and CorelDRAW for seamless design integration and job setup.

Q: What are the main operational benefits of this machine?

A: Key advantages include high cutting speeds, outstanding accuracy (up to 0.02 mm), eco-friendly operation, low noise, minimal maintenance requirements, and the ability to handle large volumes, all supported by robust safety features.
